Packaging Number
IMSA-9495B-02Z901
| Category: | Pin Header Connectors |
| Series: | 9495 |
| Drawings | |
|---|---|
| Packaging 2D: | PDF ↓ |
| Product Details | |
|---|---|
| Floating: | No |
| Connection Orientation: | Straight/Vertical |
| Pitch: | 3.8 |
| Pin Count: | 2 |
| Plating: | Tin |
| Mount: | DIP/Through-hole |
| Boss Type: | Location pin |
| Vacuum Tape Included: | No |
| Terminal Material: | Brass |
| Part Height: | 0.15-0.25 |
| Base | |
| Base Number: | Z01 |
| Mold Material: | PBT |
| Packaging Type: | Stick |
| Mating | |
| Mating Pin size / Thickness: | 0.64 |
| Mating Width: | 2.3 |
| Mating Length / Height: | 7.4 |
| Tail Length: | 3.2 |
| Total Pin Length: | 13.1 |
| Environmental | |
| Beryllium & Halogen Free: | Yes |
| Advanced | |
| High Speed: | No |
