Packaging Number
IMSA-9032B-9Z30-GF
| Category: | Pin Header Connectors |
| Series: | 9032 |
| Drawings | |
|---|---|
| Product 2D: | PDF ↓ |
| Product Details | |
|---|---|
| Floating: | No |
| Connection Orientation: | Straight/Vertical |
| Pitch: | 2.54 |
| Pin Count: | 9 |
| Plating: | Gold |
| Mount: | DIP/Through-hole |
| Boss Type: | Non |
| Vacuum Tape Included: | No |
| Terminal Material: | Brass |
| Base | |
| Base Number: | Z30 |
| Mold Material: | PBT |
| Packaging Type: | Tray |
| Mating | |
| Mating Pin size / Thickness: | 0.64 |
| Mating Length / Height: | 6.0 |
| Tail Length: | 2.8 |
| Total Pin Length: | 10.9 |
| Environmental | |
| Beryllium & Halogen Free: | Yes |
| Advanced | |
| High Speed: | No |
